1․2 Why Choose the Diamond Infinite Edge

The Diamond Infinite Edge stands out as a top choice for archers due to its unmatched adjustability and durability․ Its versatile design allows it to grow with shooters, making it an excellent investment for both beginners and experienced archers․ The bow’s lightweight and ergonomic design ensure comfort during extended use, while its smooth draw cycle and consistent back wall enhance accuracy․ Additionally, the Infinite Edge is backed by a non-transferable lifetime warranty, providing peace of mind․ Its comprehensive manual and ease of customization further solidify its reputation as a reliable and high-performance compound bow suitable for target practice and hunting alike․

Setting Up the Diamond Infinite Edge

The Diamond Infinite Edge is easy to set up by following the manual’s guidelines․ Adjust the draw length and ensuring proper string alignment for optimal accuracy․

2․1 Initial Assembly and Preparation

Begin by carefully unboxing and inspecting the Diamond Infinite Edge Bow for any damage․ Attach the limbs to the riser using the provided hardware, ensuring they are securely tightened․ Install the string and cables according to the manual’s instructions, making sure they are properly seated and aligned․ Adjust the draw weight by turning the limb bolts evenly, and set the draw length using the module screws with a 7/64 hex wrench․ Double-check the string routing and cam rotation for accuracy․ Finally, perform a safety check to ensure all components are secure and functioning properly before shooting․ Refer to the manual for detailed guidance on each step to avoid errors and ensure optimal performance․

2․2 Sighting in the Bow for Accuracy

Sighting in the Diamond Infinite Edge Bow ensures precision and consistency․ Start by setting the draw length and draw weight to your preferred specifications using the provided tools․ Attach a bow sight and level to the riser, aligning it with the string․ Shoot a few arrows at a target to gauge accuracy, adjusting the sight pins as needed․ Ensure the arrow rest and string alignment are correct for consistent arrow flight․ Fine-tune the sight and arrow placement on the bowstring for optimal performance․ Regularly check and adjust the sight-in process to maintain accuracy, especially after making any adjustments to the bow’s settings or components․

Adjusting the Bow to Your Specifications

The Diamond Infinite Edge Bow allows for precise customization․ Adjust the draw weight using the provided tools to match your strength and shooting style․

Modify the draw length and cam rotation to ensure optimal performance, guaranteeing a comfortable and accurate shooting experience tailored to your preferences and skill level․

3․1 Draw Weight Adjustment Instructions

To adjust the draw weight on the Diamond Infinite Edge Bow, start by ensuring the bow is at rest and not under tension․ Locate the limb bolts, which control the draw weight, and turn them using the provided 7/64 inch hex wrench․ Turn the bolts clockwise to increase the draw weight and counterclockwise to decrease it․ Make sure to adjust both limb bolts equally to maintain balance․ After adjusting, shoot a few arrows to test the draw weight and ensure it feels comfortable and manageable; Always refer to the official manual for specific torque specifications to avoid over-tightening, which could damage the bow․ Proper adjustment ensures optimal performance and a smooth shooting experience․

3․2 Draw Length and Cam Rotation Setup

To adjust the draw length on the Diamond Infinite Edge Bow, remove the module screws using a 7/64 inch hex wrench․ Swap the draw length modules to match your preferred setting, ensuring they are securely attached․ Next, check the cam rotation by drawing the bow and observing the cam alignment․ Proper cam synchronization is crucial for consistent performance․ If the cams are misaligned, gently rotate them until they are evenly positioned․ Use a bowstring or bow scale to verify the setup․ After adjustments, shoot a few arrows to ensure smooth operation․ Always refer to the manual for precise module configurations and torque specifications to maintain optimal bow function and accuracy․ This ensures a personalized fit and enhances shooting consistency․

Maintenance and Care Tips

Regular cleaning and lubrication of moving parts are essential․ Avoid harsh chemicals and store the bow in a dry place․ Follow the manual for guidelines․

4․1 Cleaning and Lubricating the Bow

Regular cleaning and lubrication are crucial for maintaining the Diamond Infinite Edge Bow’s performance․ Start by inspecting the bow for dirt or debris․ Use a soft, dry cloth to wipe down the frame, limbs, and strings․ For stubborn dirt, a mild detergent and water solution can be applied, but ensure all components are thoroughly dried afterward․ Lubricate the axles, cams, and other moving parts with a silicone-based spray or oil․ Avoid using harsh chemicals or excessive lubricant, as this can attract dust․ Proper cleaning and lubrication will ensure smooth operation, prevent wear, and extend the bow’s lifespan․ Refer to the manual for specific product recommendations․

4․2 Proper Storage and Transportation

Proper storage and transportation of the Diamond Infinite Edge Bow are essential to maintain its performance and longevity․ Always store the bow in a dry, cool place, away from direct sunlight and moisture․ Use a high-quality protective case or bow sleeve to prevent scratches and damage during transport․ Avoid leaving the bow in extreme temperatures or humid environments, as this can affect its components․ When transporting, ensure the bow is securely fastened and handled with care to prevent accidental damage․ By following these guidelines, you can protect your investment and ensure the bow remains in optimal condition for years to come․

Troubleshooting Common Issues

Common issues with the Diamond Infinite Edge include noise, accuracy problems, and string wear․ Regular inspection and adjustment of components can resolve most issues effectively․

5;1 Diagnosing Common Problems

Diagnosing issues with the Diamond Infinite Edge Bow begins with identifying symptoms such as unusual noise, inconsistent accuracy, or string wear․ Start by inspecting the bow’s components, including the string, cams, and limb tips, for visible damage or misalignment․ Check the draw weight and length settings to ensure they match your preferences․ If the bow produces excessive noise, it may indicate improper string lubrication or worn components․ Accuracy issues could stem from misaligned sights or improper arrow rest positioning․ For string wear, examine the serving and replace it if frayed․ Always refer to the manual for specific troubleshooting steps and use tools like a 7/64 hex wrench for adjustments․

• Inspect for visible damage or misalignment․
• Check draw weight and length settings․
• Look for string wear or improper lubrication․
• Ensure sights and arrow rest are properly aligned․

Addressing these common problems early can prevent further damage and maintain optimal performance․

5․2 Repairing and Replacing Parts

Repairing or replacing parts on the Diamond Infinite Edge Bow requires attention to detail and the use of genuine components․ Common repairs include replacing the string or adjusting the cams for proper alignment․ For parts replacement, such as the arrow rest or bow sight, refer to the official manual for step-by-step instructions․ Use a 7/64 hex wrench for draw length adjustments and ensure all modules are securely fastened․ Always source replacement parts from authorized dealers to maintain warranty validity․ Proper lubrication of moving components, like the cam system, is essential to prevent wear and tear․ Regular inspection of the bow’s limbs and string for damage is crucial to avoid costly repairs․ Addressing issues promptly ensures optimal performance and longevity of the bow․

• Use genuine parts for all replacements․
• Refer to the manual for specific repair steps․
• Lubricate moving components regularly․
• Inspect the bow frequently for damage․

Proper maintenance and timely repairs will keep your Diamond Infinite Edge Bow performing at its best․

Additional Resources and Support

For further assistance, download the official Diamond Infinite Edge Manual from Bowtech’s website․ Explore customer service, warranty details, and educational content to enhance your archery experience․ Visit Bowtech’s official website for comprehensive support․

6․1 Downloading the Official Manual

The official Diamond Infinite Edge Manual is readily available for download on Bowtech’s website or through a simple Google search․ This comprehensive guide provides detailed instructions for setting up, adjusting, and maintaining your bow․ It covers key features like draw weight adjustments, draw length settings, and cam rotation․ The manual also includes troubleshooting tips and maintenance recommendations to ensure optimal performance․ Available in PDF format, it’s easily accessible and printable for convenience․ Visit Bowtech’s official website or search for “Diamond Infinite Edge Manual” to download your copy today and ensure you’re making the most of your archery experience․

6․2 Customer Service and Warranty Information

All Diamond bows, including the Infinite Edge, come with a non-transferable lifetime warranty for the registered original owner․ This warranty protects against manufacturing defects and ensures your bow performs optimally for years․ For any inquiries or issues, Diamond’s customer service team is readily available to assist․ You can contact them directly through their official website or by phone for troubleshooting, repairs, or general questions․ Additionally, the official manual provides detailed warranty terms and conditions․ Ensure your bow is registered to take full advantage of this comprehensive coverage and dedicated support․ Diamond’s commitment to quality and customer satisfaction makes owning the Infinite Edge a hassle-free experience․
